YP-S500
ultrasonic homogenizer
Power 500W, crushing capacity 0.5-400ml

Typical applications include nanotechnology (production of nano-particle materials and graphene dispersions), cell disruption, sample preparation, homogenization, ChIP analysis, emulsification, dispersion, and deagglomeration, as well as applications in sonochemistry processing.

Product Introduction
500W ultrasonic homogenizer can safely process various organic and inorganic materials, from 250 microliters to 400 milliliters*. YP series ultrasonic products have typical applications including nanotechnology (production of nanoparticles and graphene dispersions), cell disruption, sample preparation, homogenization, ChIP analysis, emulsification, deagglomeration and disaggregation, as well as applications in sonochemical processing.

Product Introduction

500W ultrasonic homogenizer can safely process various organic and inorganic materials, from 250 microliters to 400 milliliters*.
YP series ultrasonic products have typical applications including nanotechnology (production of nanoparticles and graphene dispersions), cell disruption, sample preparation, homogenization, ChIP analysis, emulsification, deagglomeration and disaggregation, as well as applications in sonochemical processing.

Product Features
● Energy and temperature setting point control
● Digital circuit + 7-inch widescreen (touch)
● Automatic frequency tuning accurate to 1Hz + real-time monitoring of sample temperature
● 99-hour working time setting
● Variable power output control adjustable from 1 to 99%
● Electric lift + jog setting
● Frequency automatic search accuracy ±1Hz and real-time display

Technical Specifications
Model:	YP-S500
Power:	500W
Power Range:	1% - 100%
Processing Volume:	0.5ml - 400ml
Digital Intelligent Ultrasonic Generator:	Frequency Automatic Search
Resonant Frequency:	Real-time Tracking and Display
Frequency Tracking Accuracy:	1Hz, Real-time Tracking and Display
Electric Lifting Soundproof Box:	Electric Lifting and Lighting Device for the Workbench
Display:	7-inch TFT Color Screen
Frequency Range:	18kHz - 25kHz
Total Time Range:	00:00:01 - 999:99:99 (hours:minutes:seconds)
Output Time:	0.1 - 99.9 seconds
Gap Time:	0.1 - 99.9 seconds
Output Duty Cycle:	0.1% - 99.9%
物料过温保护：	1.温度设置：0-99℃ 2.当物料温度达到设定值时停止超声，当物料温度低于设定值2℃时自动恢复超声工作
存储文档：	99组
随机变幅杆：	Φ6
选配变幅杆：	Φ2 / Φ3 / Φ10
保护报警：	超温、过流、过载、换能器异常等
电源：	AC110/220V F50/60Hz
整机尺寸：	280280495
整机重量：	12.4KG
主机+换能器重量：	15.0kg
外包装尺寸：	534295435mm

Other Parameters
Transducer Weight:	1680 g
Transducer Size:	256mm×76.5mm
Random Amplitude Rod Weight:	495 g
Random Amplitude Rod Size:	140mm×6mm
Amplitude Rod Material:	Titanium Alloy Ti-6Al-4V

Probe Model Selection
Model	Cell Disruption Capacity
Φ2mm	150ul－5ml
Φ3mm	200ul－10ml
Φ6mm	10ml－150ml
Φ10mm	10ml－400ml

Single Page - Color Page
Name:	Author:	Action:
ultrasonic homogenizer YP-S500	Ultrasonic	Download

Related products
Name:	Model:
ultrasonic extraction	YP-S900
ultrasonic emulsifier	YP-S650
ultrasonic homogenizer	YP-S500

Product List

YP-S500	Unit
Host Machine	Unit
Vibration System (Transducer Assembly)	Set
Special Wrench (used for disassembling the amplitu	Set
Special Thermostatic Circulating Reaction Cup	Piece
Power cord	piece
User manual	copy
Warranty card	copy
Certificate of qualification	copy

Description: 1; 1; 1; Optional; 1; 1; 1; 1
